(UN-317) THERMODYNAMIC STEAM TRAP

THERMODYNAMIC STEAM TRAP

MODEL: UN-317   (ANSI - 600LBS, DIN PN - 40)

MATERIALS:BODYCF8M 3SCS 14CAPCF8M 3SCS 14END CAPCF8M 3SCS 14SEATCF8M 3SCS 14DISCAISI 420SCREENAISI 13GASKETRED BRonZE (JIS C1100)

SPECIFICATIONS:

◆ Working Pressure: ANSI ~600LBS. DIN PN ~40. JIS ~ 40KG/CM2

◆ Test Pressure: Body: 1200 PSI.  PN 80.  80 KG/CM2

◆ Working Temperature: Max allowable 250℃ / 482℉

                                     Body: Max 400℃ / 752℉

◆ Thread end: BS21, ANSI or DIN 259.

◆ Special order: for size 3/8" and Socket Weld end Acc. to ANSI

◆ Max. back pressure should not exceed 80% of inlet pressure.

DIMENSION:        mm LHH13/8".91/2".93/4".21".0
